500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine

Brand Name:	GUTE
MOQ:	1
Price:	US$58,000

Detail Information

Product Description

Detail Information

Place of Origin:

Sichuan, China

Voltage:

380V

Dimension:

30*5*3 M

Power:

42kw

Weight:

15000 Kg

Cutting Edge Width:

500mm

Shearing Mode:

Hydraulic Shearing

Roller Speed:

0-100m/min Adjustable

Maximum Shear Length:

12m

Minimum Shear Length:

1.4m

Shear Accuracy:

±5mm

Shear Frequency:

≤12n/min

Silo Series:

Blade Thickness:

40mm

Pay-off Capacity:

2500KG

Servo Motor Power:

16KW

Highlight:

500mm hydraulic rebar shear

42kw industrial cutting machine

380V rebar shear line

Product Description

High-performance Custom Cutting Edge Width 500mm Rebar Shear Line Rebar Shear Line SGS150

Product Specifications

Attribute	Value
Video Outgoing-Inspection	Provided
Machinery Test Report	Provided
Core Components	Motor
Voltage	380V
Dimension (L×W×H)	30×5×3 m
Power (kW)	42
Weight (kg)	15000
Key Selling Points	Easy to Operate
Warranty	1 Year
Cutting Edge Width	500mm
Shearing Mode	Hydraulic shearing
Roller Speed	0-100m/min adjustable
Maximum Shear Length	12m
Minimum Shear Length	1.4m
Shear Accuracy	±5mm
Shear Frequency	≤12n/min
Silo Series	3
Rated Power	42kw
Total Weight	15t

Product Description

CNC REBAR SHEAR LINE SGS150

PLC control shearing precision, high precision of finished steel bar, suitable for shearing processing of steel bar with many specifications and small batches.
The machine has 24 fixed length plates, all of them are steel plate structure, with fixed length servo motor, the fixed length is fast and accurate.
Large length blade and inclined blade design ensure that multiple reinforcing bars can be cut simultaneously.
Equipped with centralized oil supply system to ensure long life operation.
Level 3 product storage mechanism facilitates the collection of multiple products.
Thickened and widened gears, stable and efficient cutting, fully encapsulated shield for enhanced safety.
The positioning screw adopts high strength spiral elevator, which is not easy to deform and has high positioning accuracy.
The cutting length can be set arbitrarily and work continuously. The speed block can be conveyed, and the cutting accuracy of fixed length is high.
Chains have keys as guide ways, and chains and guide ways are rolling friction. They have small wear and tear, long service life and high transmission efficiency.

Cutting edge width	500mm
Shearing mode	Hydraulic shearing
Roller speed	0-100m/min adjustable
Maximum shear length	12m
Minimum shear length	1.4m
Shear Accuracy	±5mm
Shear frequency	≤12n/min
Silo Series	3
Rated power	42kw
Total weight	15t
Long × wide × high	30m×5m×3m
Length Control Mode	Servo

Straightening Structure

Straightening wheel for forging alloy tool steel manufacturing, wear resistance, impact resistance.
Preset wheel plate: the overall use of 30mm thick steel plate, high strength, strong impact load, very durable.

Multi-split Type Blade

The adoption of multi-split type blade which ensures a double lifetime compared with normal one piece blade.

Servo Motor

Equipped with 16KW high-power servo motor to ensure the smooth operation of traction.

Pneumatic Element

Pneumatic components adopt famous brand Airtac of Taiwan, ensure the service life.
Split thickening blade design, thickness up to 40mm, easy to use for many times.

Pay-Off

Each machine with 2 pcs pay-off.
Each pay-off Maximum carrying capacity 2500KG.
Be able to dis-assemble and easy to transport.
You can customize the pay-off with brake.

Automatic Collector (Optional)

Automatic collection of finished stirrups.
The collection quantity can be set. Easy to pack finished products.

Application

Production Line

Company Profile

GUTE is the MANUFACTURER of construction machinery with 28 years history and more than 250 workers to produce steel bar processing machinery.

Now already exported more than 70 countries and 70% exporting share of steel bar bender/cutter
With more than 200 agents in Chinese market and 10 owned brand shops in different provinces in China.
We OEM for many very famous European brand for these kinds of machine.

Now, our machines already sold to Russia, Italy, Brazil, Algeria, India, Argentina, Saudi Arabia, Middle East and more than 70 countries and regions of the world.

We are reinforcement steel bar bending, shearing, welding, straightening machine provider. Expert with fast and professional customized services, in R&D and quality control of new products and special accessories for different market needs. We are having highly precise, durable semi-automatic and fully automatic steel bar machines.

Transportation

FAQ

Q: What's the producing time and delivery time?

A: Order less than 5 pcs, we have stock, delivery to Shanghai port about 5 days. And order more than 5 pcs, about 10-15 working days.

Q: What's the MOQ?

A: 5 pcs. For sample order, 1 pc is OK, there's extra port and delivery charges.

Q: What's the departure port?

A: Usually Shanghai port, Guangzhou, Qingdao, Tianjin and other Chinese port is also OK.

Q: What's the packing?

A: Iron Pallet and Polly wooden cases (no fumigation needed).

Q: What's the payment term?

A: T/T, L/C, DP, West union, PayPal.

Our Service

Your inquiry related to our products or prices will be replied in 24 hours.
Protection of your sales area, ideas of design and all your private information.
Best quality and competitive price.
