High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant

Brand Name: GUTE
Model Number: SGW08A
MOQ: 1set
Price: 11000-13000USD/SET
Packaging Details: plywood case
Payment Terms: L/C, T/T, D/P, D/A
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ISO 9001:2000
SINGLE WIRE BENDING:
4-8 Mm
DOUBLE WIRE BENDING:
4-6mm
MAX. BENDING ANGLE:
180°
MAX. LENGTH OF STIRRUP SIDE:
700 Mm
MIN. LENGTH OF STIRRUP SIDE:
60 Mm
BENDING DIRECTION:
One-direction
Bend Control Method:
Servo
Maximum Bending Angle:
700mm
Rib Length Accuracy:
±5mm
Power Consumption:
3KW/H
Supply Ability:
200set/month
Highlight:

CNC Stirrup hook Bender

,

High Efficiency CNC Stirrup hook Bender

Product Description
High-Efficiency CNC Stirrup hook Bender For Steel Processing Plant
01


Overview

This is a very cost-effective CNC steel bending machine, suitable for small steel processing plants to use. Do not need an air compressor and oil, high efficiency, low maintenance costs. Can process a variety of graphics, hoop machine, circle, retractor, and other reinforcement graphics.

02


Scope of application

Mainly used in the construction of housing construction, steel processing plant​

03


Device parameters

Single wire bending diameter 4–8mm
Double wire bending diameter 4–6mm
Processing material Steel coil
Maximum towing speed 75-100 m/min
Maximum towing speed 1200°/sec
Rib straightness error 0.02/m
Total power 12KW
Power consumption 3KW/H
Bending direction One-direction
Stirrup length accuracy ±1mm
Rib length accuracy ±5mm
Angle accuracy ±1°
Maximum bending angle ±180°
Maximum bending angle 700mm
Shortest stirrup side 60mm
Working temperature -5~40 ℃
Traction control method Servo
Bend control method Servo
Loopback control method Servo
Total Weight 1.2T
04


Equipment advantages

  • 1200-2400 stirrups production per hour, 1200 stirrups for 8mm single-wire,2400 stirrups for double-wire.
  • 1 year free warranty service.
  • The electric components are of famous brands such as CHINT and MEAN WEL. The power of traction and bending is provided by a servo motor, with high efficiency and accuracy Supports multi - language interactive interface, and simple operation.
  • Each transmission system adopts standard reducer transmission, with stable structure and high transmission efficiency.
  • Lightweight and compact body, more convenient and easy to transport and install.
  • The production system structure does not require air source and hydraulic pressure, it can be used immediately after plugging in, and the use cost is lower, convenient and fast.
  • Function:
  • This machine can process stirrup square, rectangular, circles, hooks, long straight bar and so on hundreds of shapes.
  • Process §4-8mm single wires and §4-6mm double wires for deformed steel coil.

.

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 0

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 1

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 2
High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 3

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 4

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 5

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 6








Our factory

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 7

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 8








Our service

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 10










Certification

High-Efficiency CNC Stirrup Hook Bender For Steel Processing Plant 11
