GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender

Brand Name:	GUTE
Model Number:	SGW12D-3D
MOQ:	1set
Price:	40000-50000USD/SET
Packaging Details:	plywood case
Payment Terms:	L/C, T/T, D/P, D/A

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ISO 9001:2000

MODEL:

SGW12D-3D

SINGLE WIRE BENDING:

5-12mm

DOUBLE WIRE BENDING:

5-10 Mm

MAX. LENGTH OF STIRRUP SIDE:

900 Mm

MIN. LENGTH OF STIRRUP SIDE:

140 Mm

BENDING DIRECTION:

Single-direction

WEIGHT:

TOTAL POWER:

Supply Ability:

200set/month

Highlight:

GUTE Automatic Stirrup Bending Machine

GUTE 12mm Wire Bar Bender

single direction 12mm Wire Bar Bender

Product Description

3D CNC Steel Bar Stirrup Bending Machine 12mm Wire Bar Bender

Overview

This machine can process 3D shapes, horseshoes, stirrup, circles, hooks H-shaped steel, long straight bar and so on hundreds of shapes.
Process §5-13mm single wires for deformed steel coil.
1600 stirrups production per for hour and each batch can be yield up to 8tons.
1 years free warranty service.
The electric components are of famous brands such as Schneider the power is provided by servo motor, with high efficiency and accuracy Support multi - language interactive interface, simple operation.
Draw the steel coil in a straight line and bending with cutting.
sheet metal panel, observing the door with a standard 5mm, long service life, more wear-resisting.
IKO bearings imported from Japan are used in key parts to ensure service life.
Straightening wheel made of alloy steel service life is longer.

Finished products

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 0

Device parameters

Single wire bending diameter	5–12mm
Rebar double wire bending diameter	5–10mm
Maximum bending speed	1050°/sec
Rib straightness error	0.02/1m
Total power	33KW
Power consumption	5KW/H
Stirrup length accuracy	±1mm
Rib length accuracy	±5mm
Longest stirrup side	900mm
Shortest stirrup side	140mm
Total Weight	3.5T

Equipment advantages

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 1

Equipped with 22KW high-power servo motor to ensure the smooth operation of tractio.

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 2

The adoption of multi-split type blade which ensures a double lifetime co-mpared with normal one piece blade

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 3

The touch screen console can store 500 hundreds of graphics and is easy to operate.

Our factory

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 4

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 5

Our service

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 7

Certification

GUTE Automatic Stirrup Bending Machine Single Direction 12mm Wire Bar Bender 8
