Product Details:
Payment & Shipping Terms:
|
| MODEL: | SGW12A | SINGLE WIRE BENDING: | 5-13mm |
|---|---|---|---|
| DOUBLE WIRE BENDING: | 5-8 Mm | MAX. LENGTH OF STIRRUP SIDE: | 900 Mm |
| MIN. LENGTH OF STIRRUP SIDE: | 140 Mm | BENDING DIRECTION: | Single-direction |
| LENGTH ACCURACY: | ±1mm | L×W×H: | 3600×1460×1950 Mm |
| WEIGHT: | 1.5T | WARRANTY: | 1 Year |
| Highlight: | single direction CNC Stirrup Bending Machine,single direction Steel Wire Bender machine,GUTE Steel Wire Bender machine |
||
Overview Finished products Device parameters 100 m/min 1050°/sec Equipment advantages Our factory Our service Certification
1. IKO bearings imported from Japan are used in key parts to ensure service life.
2. 1600 stirrups production per for hour and each batch can be yield up to 8tons.
3. The the power is provided by servo motor, with high efficiency and accuracy Support multi - language interactive interface, simple operation
4. Bending down only.
.
Single wire bending diameter
5–12mm
Rebar double wire bending diameter
5–8mm
Processing material
Steel Coil
Maximum towing speed
Maximum bending speed
Rib straightness error
0.02/1m
Total power
31KW
Power consumption
5KW/H
Stirrup length accuracy
±1mm
Rib length accuracy
±5mm
Angle accuracy
±1°
Maximum bending angle
±180°
Longest stirrup side
900mm
Shortest stirrup side
140mm
Working temperature
-5~40 ℃
Total Weight
1.5T
