| Max. Bending Angle: | 180° | Max. Bending Diameter: | 18mm |
|---|---|---|---|
| Installed Power: | 8kw | Machining Precision: | Length ±2 Angle ±1 |
| Rebar Straightness Error: | 0.02/1m | Total Weight: | 1.6T |
| High Light: | 18mm Automatic Rebar Bending Machine,automatic rebar stirrup bending machine 1.6T,18mm automatic rebar stirrup bending machine |
||
1. The Sww-18 shaped hoop center is currently the equipment that can process the shortest side length in the same kind of five bending hoop machines.
2. The Sww-18 adopts hydraulic transmission, the horsepower is strong, the total number of steel bar bending os most compared to the same volume or the least short edge equipment (the form is marked with the specification of Q235 round steel)
3. Sww-18 adpots the world's leading brand PLC control system to realize the perfect control of the equipment, and monitor the fault in real time for the equipment, and realize the perfect combination of man and machine.
Technical Parameters
| Max. Bending Angle | 180 | model optional length | 4m/6m/9m | ||||||
| Max. Bending Diameter | 18mm | weight | 4m | 6m | 9m | ||||
| Installed Power | 8kw | 1400kg | 1650kg | 1850kg | |||||
| Machine precision | ±2 | L*W*H | 4110*1480*1100mm | ||||||
| Type of stirrups | 11 | processing capacity | 50 | 40 | 32 | 25 | 20 | 16 | 12 |
| 1 | 2 | 6 | 15 | 20 | 25 | 40 | |||
